Welcome to Ham Radio Network - Reliable Communication for All

GB7ESC Node

System Overview

Once connected, GB7ESC-1 offers a suite of packet radio services designed to support both casual users and advanced operators:

📡 Node Routing & Forwarding

Seamlessly connect to other BPQ nodes across the network. Use to list available nodes and to initiate a link. Routing tables are updated regularly to ensure reliable paths.

💬 Chat & Mail Services

Engage in real-time chat with other connected users or leave messages via the mail system. Use to enter the chat room or to access personal mailboxes.

📬 BBS Access

Browse bulletins, post messages, and retrieve information from the local BBS. Enter to launch the BBS interface. You can also use to send private messages or to post bulletins.

🌐 Gateway Links

Connect to internet-linked services or cross-band nodes (if configured). These may include telnet gateways, HF forwarding, or APRS integration depending on current setup.

Welcome to GB7ESC-1, your gateway to packet radio services on HF, 2m and 70cm bands. This node supports AX.25 connections and offers a range of features for amateur radio operators.


🔹 Available Ports

  • Port 1 – 2m Band
  • SSID: GB7ESC-1
  • Freq: 144.9375Mhz
  • Mode: AX.25
  • Baud Rate: 1200 baud
    .
  • Port 4 – 70cm Band
  • SSID: GB7ESC-1
  • Freq: 439.950Mhz
  • Mode: IL2P
  • Baud Rate: 9600 baud IL2P

    Port 5 – 20M Band
  • SSID: GB7ESC-1
  • Freq: 14.1.0750Mhz
  • Mode: AX.25
  • Baud Rate: 300 baud

    Updated 13th August 2025
